TQ Rollers
Lighter than steel roller, no damage to conveyor belt
TQ Roller HDPE Ø133
TQ Roller HDPE Ø133
TQ Rollers
High Density Polyethylene Conveyor Rollers
✓ Cheaper than stainless steel (INOX)
✓ Lighter than steel rollers
✓ Perfect sealing / triple labyrinth
✓ Little adhesion to material
✓ More silent than steel rollers
✓ No damage to conveyor belt
✓ Closed bearing
✓ Long life expectancy
| Roll diameter 133 mm | Axis diameter 25 mm & diameter 30 mm | |||||||||
| Roll length (mm) | 200 | 250 | 315 | 380 | 465 | 600 | 750 | 950 | 1150 |
| Axis length (mm) | 226 | 276 | 341 | 406 | 491 | 626 | 782 | 982 | 1182 |
| Standard key (mm) | 14 x 10 | 15 x 10 | 15 x 13 | 17 x 10 | 18 x 10 | 18 x 13 | 22 x 10 | 22 x 13 | |
| Also available in roll diameter 89 mm, 108 mm & 159 mm | |||||||||
✓ No damage to conveyor belt |
✓ More silent than steel |
✓ Lighter than steel roller |
